MP60 Ultrathin Mixer Amplifier

● Rated power 35W/60W/120W, 70V/100V&4-16Ω output
● Built-in high efficiency digital amplifier module and switching power technology,
● with 100V/70V transformer
● Compact 1 U mini size public address amplifier
● Line 1-2 input of RCA input and one RCA line output
● Mic. 1 of 6.35mm in front panel with priority & muting
● Mic. 2 of balanced XLR in rear panel
● Built-in EMC input of 100V and 300MV for emergency use



Introduction

MP60 is a small power mixer amplifier, compact, cost-effective. Suitable for small-sized broadcast system,the background music in supermarket, and public address in the classroom. It’s very thin with 1 U height. It support priority and two modes of power supply — AC and SD. It has line 1-2 input and one line output. This power mixer amplifier for sale is also your best choice.



Specification

Model MP60
Rated power 60W
Input sensitivity MIC 5mV
LINE、EMC 775mV
Noise MIC ≥60 dB
LINE、EMC ≥70 dB
Frequency response MIC 100Hz-10kHz

80Hz-16kHz

LINE EMC
THD ≤0.2%(1kHz ,1/3 output voltage)
Operating temperature -20℃-50℃
Rated output 70V/100V support 4-16Ω
Line output 1V RMS
Tone Bass ±10dB (100Hz)
Treble ±10dB (10kHz)
2 MIC(MIC1with priority) MIC1 input by 6.3 socket,MIC2 by XLR socket and shared front panel LINE2 knob,with Phantom power switch,with GAIN control,-10dB to +10dB
Speaker Outputs COM 4-16Ω,70V,100V,24V input
Power supply 110-240V/50-60Hz  DC24V
Power consumption 78W
Packing size(mm) (L×W×H) 333×292×90
Equipment size(mm) (L×W×H) 206×250×44
Gross weight 3.10kg
Net weight 2.45kg



Connection
